Exercise 4: Event-Driven Application

Objective: Build an application that responds to drawing events and provides real-time feedback.

Step 1: Add Statistics Display

Add statistics tracking to your HTML:

<div id="app-stats">
    <h3>Drawing Statistics</h3>
    <div id="feature-stats"></div>
    <div id="selection-info">No feature selected</div>
</div>

Step 2: Implement Statistics Tracking

interface AppStats {
    points: number;
    lines: number;
    polygons: number;
    rectangles: number;
    totalArea: number;
    totalLength: number;
}

let currentStats: AppStats = {
    points: 0,
    lines: 0,
    polygons: 0,
    rectangles: 0,
    totalArea: 0,
    totalLength: 0
};

function updateStatistics() {
    const features = draw.getSnapshot();

    currentStats.points = features.filter(f => f.geometry.type === 'Point').length;
    currentStats.lines = features.filter(f => f.geometry.type === 'LineString').length;
    currentStats.polygons = features.filter(f => f.geometry.type === 'Polygon' && f.properties.mode === 'polygon').length;
    currentStats.rectangles = features.filter(f => f.geometry.type === 'Polygon' && f.properties.mode === 'rectangle').length;

    displayStatistics();
}

function displayStatistics() {
    const statsElement = document.getElementById('feature-stats');
    if (statsElement) {
        statsElement.innerHTML = `
            <div>Points: ${currentStats.points}</div>
            <div>Lines: ${currentStats.lines}</div>
            <div>Polygons: ${currentStats.polygons}</div>
            <div>Rectangles: ${currentStats.rectangles}</div>
        `;
    }
}

Step 3: Add Selection Feedback

draw.on('select', (event) => {
    const infoElement = document.getElementById('selection-info');
    if (infoElement && event.selectedFeatures.length > 0) {
        const feature = event.selectedFeatures[0];
        infoElement.innerHTML = `
            <h4>Selected Feature</h4>
            <div>Type: ${feature.geometry.type}</div>
            <div>Mode: ${feature.properties.mode}</div>
            <div>Feature Type: ${feature.properties.type || 'default'}</div>
        `;
    }
});

draw.on('deselect', () => {
    const infoElement = document.getElementById('selection-info');
    if (infoElement) {
        infoElement.innerHTML = 'No feature selected';
    }
});

Step 4: Real-time Updates

Connect all events for real-time updates:

// Update stats on any change
draw.on('change', updateStatistics);

// Log drawing activity
draw.on('draw', (event) => {
    console.log(`New ${event.feature.geometry.type} drawn in ${event.mode} mode`);

    // Show temporary notification
    showNotification(`Created ${event.feature.geometry.type}`);
});

function showNotification(message: string) {
    const notification = document.createElement('div');
    notification.className = 'notification';
    notification.textContent = message;
    notification.style.cssText = `
        position: fixed;
        top: 20px;
        right: 20px;
        background: #10B981;
        color: white;
        padding: 10px 15px;
        border-radius: 4px;
        z-index: 1000;
    `;

    document.body.appendChild(notification);

    setTimeout(() => {
        notification.remove();
    }, 2000);
}

Step 5: Add Export with Statistics

function exportWithStats() {
    const features = draw.getSnapshot();
    const exportData = {
        type: 'FeatureCollection',
        features: features,
        metadata: {
            exportedAt: new Date().toISOString(),
            statistics: currentStats,
            totalFeatures: features.length
        }
    };

    const blob = new Blob([JSON.stringify(exportData, null, 2)], {
        type: 'application/json'
    });
    const url = URL.createObjectURL(blob);

    const a = document.createElement('a');
    a.href = url;
    a.download = `terra-draw-export-${Date.now()}.geojson`;
    a.click();

    URL.revokeObjectURL(url);
}

Step 6: Test Your Application

1. Draw various features and watch statistics update in real-time
2. Select different features and see the selection information
3. Watch for notifications when creating new features
4. Export the data and examine the metadata included

Expected Results

After completing this exercise, your application should: - Show real-time statistics as you draw - Display information about selected features - Show notifications for user actions - Export data with metadata and statistics

What's Next?

You've mastered Terra Draw's advanced features! Now let's explore the maplibre-gl-terradraw plugin for enhanced MapLibre integration.

Next: MapLibre Integration
